    Drive Axle Truck Oil Seals , Tractors Polyurethane Shaft Custom Oil Seals

    Ask Lasest Price
    Certification : ISO-9001:2000, ISOTS16949
    Payment Terms : L/C, T/T
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Drive Axle Truck Oil Seals , Tractors Polyurethane Shaft Custom Oil Seals


    Product Description


    Product nametruck Polyurethane Sahft Oil Seal
    MaterialNBR FKM VMQ PTFE and others
    ColorBrown, yellow, black, red, blue, white, green, transparent and others
    Size

    customized size accepted
    both standard or non standard size

    TypeTB, TC, etc
    FeatureEasy to compress, easy to recover
    Anticorrosion/antiage/anti-friction
    Heat/cold/chemical/Ozone /wearing resistant
    Multiple styles/colors/models(more than 4000)
    Wide usage, High quality, Soft and good elasticity
    Water proof/oil proof/dus tproof/wear proof/air proof
    Working Temperature- 40℃ ~200℃
    ApplicationAgricultural machinery, engineering machinery
    OEM/ODMavailiable
    Hardness30-90 Shore A, as you required
    PackingInner is poly bag and outer is carton
    Factory historymore than 40 years experience in oil seal industry

    The Oil Seal and dust seal are combined in one metal case, ready for use. Cassette seal used for Agricultural machinery: tractors/hub tractors/propeller shafts, Harrows, Motorised cultivators, Tillers, Fertiliser spreading machinery. Construction machinery (road rollers, excavators, fork-lift trucks, mixers, Axles: hubs Axles: propellers shafts).




    Oil seal catalog structure


    Common types of high demond nbr/fkm//fpm oil seals and rubber productss
    TypeCode numberMain featuresUsageDielectric pressure resistanceMaximum line speed
    Simple single lippedBIt is commonly used for high and low speed rotating shafts and reciprocating movement to seal mineral, oil and water.Ordinary high demond nbr/fkm//fpm oil seals and rubber products, in the case of less dust and impurities, the use of medium pressure, the reciprocating speed of <0.1m/s.<0.05MPa15m/s
    Regular lipFBIn addition to the characteristics of the above S type high demond nbr/fkm//fpm oil seals and rubber productss, dust can be prevented.Ordinary high demond nbr/fkm//fpm oil seals and rubber products, with dustproof lips, dustproof, resistant to medium pressure<0.05MPa15m/s
    No spring typeBVSpring free single lip type inner frame type rubber high demond nbr/fkm//fpm oil seals and rubber products.Generally applicable to low-speed conditions, the sealing medium for the lubrication of ester.<0.05MPa6m/s
    Outer skeleton, single lipWWith the spring single lip exposed skeleton rubber high demond nbr/fkm//fpm oil seals and rubber products, waist thin, follow good, good rigidity.Ordinary high demond nbr/fkm//fpm oil seals and rubber products, used in case of less dust and impurities<0.05MPa15m/s
    Outer skeleton, double lipsFWWith the lips of the lips exposed, skeleton rubber high demond nbr/fkm//fpm oil seals and rubber products, waist thin, followed by good, high stiffness, good coaxial.Ordinary high demond nbr/fkm//fpm oil seals and rubber products, with dustproof lips, dustproof, resistant to medium pressure <0.05<0.05MPa15m/s
    Fabricated single lippedZFrom the inside and outside the outer skeleton high demond nbr/fkm//fpm oil seals and rubber products skeleton assembly into piping and installation of high precision, fast heat dissipation, heavy load characteristics.Suitable for heavy load under high temperature and high speed condition<0.05MPa15m/s
    Fabricated double lippedFZThe assembled external skeleton high demond nbr/fkm//fpm oil seals and rubber products with side lip has the characteristics of dust resistance, high installation accuracy, fast heat dissipation and heavy load characteristics.Apply to high temperature, high speed, heavy load under dust condition≤0.05MPa15m/s
    Unidirectional reflux typeDextral SR,Levo DLA diagonal bar with angle in lip air measurement system using fluid mechanics principle, produces pump function, with reflux effect.Because of the backflow effect, the radial force is smaller than that of the ordinary high demond nbr/fkm//fpm oil seals and rubber products, thereby reducing wear and heat build-up and improving service life<0.05MPa20m/s
    Pressure typeNYThe lip is short, stubby waist, with pressure, work pressure is less than 3MPa.The shaft end high demond nbr/fkm//fpm oil seals and rubber products for high pressure pump, general PV value is less than or equal to 8≤3MPa15m/s



    Why choose us


    1. We have more than 40 years' experience in rubber seal and machined metal parts industry.
    2. Research team. R&D for dfferent customer requirement to meet usage requirements.
    3. OEM/ODM Service are available. We can design and producets variours Non-standard Rubber Parts according to your requirement.
    4. ISO-90012000 and ISOTS16949 certificate.
    5. Kinds surface treatment based on customer requirement.
    6. All products are 100% inspected before shipment !
