    Custom Size U Type Seal UN Or UHS Type 70-90 ShoreA Hardness Easy To Install

    Ask Lasest Price
    Model Number : UHS, UN
    Certification : ISO-9001:2000 system, ISO/TS 16949
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Custom Size U Type Seal UN Or UHS Type 70-90 ShoreA Hardness Easy To Install


    Product nameUN/ UHS PU seal
    Material

    PU, etc.

    Hardness

    70-90 shoreA

    Temperature-35℃-120℃
    ColorTransparent, Green, Blue, Light Yellow, etc
    Sizestand size or customized size
    Mediumhydraulic oil, flame retardant oil, water, gas
    Advantages

    1.Excellent wear resistance

    2 is not sensitive to impact loads and pressure peaks

    3. High extrusion resistance

    4. Low permanent compression deformation

    5 suitable for harsh working conditions

    6 easy to install

    Application

    household appliances, automobile, steamboat, industrial electrical equipment, building door& window etc.

    Resistance

    Oil, abrasion, solvent,weather

    PackageInner plastic bag/outside carton
    CertificateISO-9001:2000, ISOTS16949









    PY UHS type Seal



    ITEMd×D×HITEMd×D×HITEMd×D×H
    UHS 1414×22×5UHS 5858×68×6UHS 120120×135×9
    UHS 1616×24×5UHS 6060×70×6UHS 125125×140×9
    UHS 1818×26×5UHS 6060×71×7UHS 130130×145×9
    UHS 2020×28×5UHS63×73×6UHS 132132×145×9
    UHS 2222×30×5UHS 6565×75×6UHS 136136×150×9
    UHS 22.422.4×30×5UHS 6767×77×6UHS 140140×155×9
    UHS 23.523.5×31.5×5UHS 7070×80×6UHS 145145×160×9
    UHS 2525×33×5UHS 7070×85×9UHS 150150×165×9
    UHS 2828×35.5×5UHS 7171×80×6UHS 155155×170×9
    UHS 3030×40×6UHS 7575×85×6UHS 160160×175×9
    UHS 31.531.5×41.5×6UHS 8080×90×6UHS 165165×180×9
    UHS 3232×42×6UHS 8585×95×6UHS 175175×190×9
    UHS 3535×45×6UHS 8585×100×9UHS 180180×200×12
    UHS 35.535.5×45×6UHS 9090×105×9UHS 190190×210×12
    UHS 3838×48×6UHS 9595×110×9UHS 200200×220×12
    UHS 4040×50×6UHS 9898×112×9UHS 204204×244×12
    UHS 4545×55×6UHS 100100×115×9UHS 210210×220×12
    UHS 4545×56×7UHS 105105×120×9UHS 224224×244×12
    UHS 4848×56×6.5UHS 106106×120×9UHS 230230×250×12
    UHS 5050×60×6UHS 110110×125×9UHS 235235×260×9
    UHS 5353×63×6UHS 112112×125×9UHS 240240×260×9
    UHS 5555×65×6UHS 115115×130×9UHS 250250×270×12
    UHS 5656×66×6UHS 118118×132×9UHS 260260×280×14

    UN/UPH PU Seal


    ITEMd×D×HITEMd×D×HITEMd×D×H
    UN 1414×24×8UN 3232×45×10UN 6364×83×12
    UN 1616×26×8UN 3535×50×10UN 6565×85×12
    UN 1818×28×8UN 35.535.5×50.5×10UN 6767×87×12
    UN 2020×30×8UN 4040×55×10UN 7070×90×12
    UN 21.521.5×31.5×8UN 4545×60×10UN 7171×91×12
    UN 2222×35×10UN 4848×63×10UN 7575×95×12
    UN 22.422.4×32.4×8UN 5050×65×10UN 8080×100×12
    UN 2525×35×8UN 5050×63×10UN 8585×105×12
    UN 2727×40×10UN 5555×75×12UN 9090×110×12
    UN 2828×43×10UN 5656×76×12UN 9595×105×12
    UN 3030×45×10UN 6060×80×12UN 100100×120×12

    This is the part list of UHS, UN/UPH type PU seal, more dimensions pls contact me.


    Our Advantages

    1. Available material: NBR, HNBR, EPDM, ACM, Silicone, (FKM), etc. Wide range of material is available.
    2. All manufacturing processes confirm to the ISO-9001:2000 system, ISO/TS 16949.
    3. Excellent chemical and physical property, excellent in oil resistant, high/low temperature-resistant, wearing-resistant, oil-resistant, dust-resistant.
    4. Custom: design and manufacture complete sets of rubber parts based on customer's requirements, any specification is welcome according to your requirements.
    5. Available in various sizes and colors.
    6. State standard and non-state standard sizes available.
